Aikan - Biogas Plant
An Aikan plant handles solid waste and wastewater or slurry from livestock. Our solutions include both pre-treatment of the waste and handling of the end-user products.
Products Details
At least 60 % of the biogas potential in the solid waste creates revenue in form of biogas production. The biogas consists of more than 70 % of methane due to the unique process design. The solution can be designed to exploit methane for transportation or to sell electricity and heat.
The biogas production in an Aikan plant is based on a thoroghly tested and robust anaerobic batch process divided into a dry phase in process modules and a wet phase in reactor tanks. Solid wastes are handled in the process modules, which are subsequently used for in-vessel composting. This dry treatment also provides high tolerance of impurities in the waste. Traceability can be secured by treating different types of waste separately.
The organic content in wastewater and in slurry from livestock degrades in the reactor tanks.
The flexibility of our solution provides good opportunities to ensure an optimal value chain in different and changing scenarios.
How it Works
Due to its unique design, Aikan Technology allows for batch processing of waste, producing both biogas and compost, without moving the solid waste fraction. An Aikan plant is one of the most effective and flexible solutions available for integration with mechanical biological treatment (MBT). It is a hybrid solution which brings anaerobic digestion and in-vessel composting into a single highly flexible production work flow.
An Aikan system is laid out in such a way that it physically separates hydrolysis (“leaching out”) and methane generation, the two main processes that constitute what is generally known as dry anaerobic digestion.
The performance of an Aikan system relies on the following 3 steps:
Hydrolysis: Inside the process module fresh waste is sprayed with degasified percolate drawn from the biogas reactor. This induces bacterial hydrolysis, leaching out fatty acids. Percolate is drained from the bottom of the process module, effectively separating the waste into dry and wet fractions.
Methane production: The wet fraction (the percolate), with its content of fatty acids, is pumped back to the biogas reactor where methane production takes place, physically separated from the solid waste fraction. Steps 1 and 2 are continued as long as the percolate has potential for methane production.
Composting: When the potential for methane production has decreased, the process module switches to forced ventilation (negative aeration) of the remaining solid waste. Aeration rapidly initiates a highly effective composting process. Heat from the composting ensures complete sanitization and evaporation of excess humidity.
During all 3 steps, the process module remains clo...
During all 3 steps, the process module remains closed. No solid waste is moved, with only fluids and air circulating between the process module and the gas reactor in a closed system. The system design ensures that the processes of hydrolysis, percolation, methane generation and composting are separate and occur rapidly and extremely efficiently. There is no need for inoculation using earlier processed material to start fresh batches. This insures full traceability.
Aikan Technology optimizes transformation processes that occur naturally in the decomposition of biological waste and makes sure that the outputs can be captured, upgraded and turned into valuable resources that can be recycled. The unique design of the Aikan process allows for the use of reliable and readily available standard technology.
The term “Dry AD” can be a little confusing as the process as such is not dry. “Dry AD” means that the solid waste is handled in solid form whereas “Wet AD” means that the waste is made into a pulp which are pumped around.
