ELF - Model DN15-20 - Compact Heat Meter with Rotating Flow Transducer
From Water and Heat Metering- Heat Meters
Precise and reliable heat meter, equipped with high class heat calculator and flow transducer of class 2, with electronic detection of rotor rotation and archiving many of data readings. It is distinguished by its modern design. Heat meter for measuring the consumption of heat energy drawn from heat networks by small residential or office buildings. Heating factor with a temperature up to 90 °C (105 °C**) and maximum working pressure up to 16 bar (PN16). Suitable for installation in the horizontal hoses (pipelines) with the counter directed upwards (H), or in vertical hoses (V).
-
Most popular related searches
Metrological class
Metrological class
Class 2 – H
Class 3 – V
Product features
- The modern multi-functional microprocessor heat counter
- Maintenance using one button
- Power supply independent – battery powered
- Standard version battery life is 5 years +1 year, special version battery life is 10 years + 1year
- Fully resistant to strong external magnetic field
- Flat characteristics of flow transducer error
- Highly accurate readings (Class 2)
- Sensors’ connecting cable 2ms
Removable communication modules
- M-Bus + 4 impulse inputs
- M-Bus + 2 impulse inputs + 1 impulse output
- 4 impulse inputs (possibility of independent configuration of impulse weight of each output)
- 3 impulse inputs + 1 impulse output
- Radio module (Wireless M-Bus)
- Service module (configuration module) – USB
