Model BT 4 - Single Stage Back Pressure Turbine
The BT 4 turbine is best known as the first step towards co-generation, as it provides a stepping- stone to understand the basics of balancing steam and power. Induction generator based examples offer an even greater degree of freedom for users that want to synchronise their machines with the grid. These turbines have been serving our customers since the year 2001, and greater than 300 are in active service today.
-
Most popular related searches
Features
BT-4 is a Curtis design turbine that has a low CF rotor. The rotor is supported on both sides by high- speed bearings.
- The BT Series has been specially designed for continuous operation as repeated startup and shutdown cycles.
- As a synchronised turbine, it can be fitted with induction generators or alternators and can meet varying steam loads effortlessly to deliver constant back pressure.
- Can be provided with Hydro-Mechanical or Electronic Governors.
- No requirement for Control Oil System.
- Due to low internal losses, it is well suited to applications with low steam flow.
- As a base load turbine, it meets the exacting performance of a work horse.
- Suitable for Mechanical drive Operation.
- A highly proven, rugged and reliable design, it can be adopted for all small Cogen applications.
- High level of standardisation has ensured that parts are available immediately, reducing turbine downtime.
